CW-M3、CW-M5、CW-M6、CW-M8、CW-M7、CW-M9、CW-M10、CW-M14、CW-M12、CW-M20 关节

ROD END NO.

DIMENSIONS IN MILLIMETERS

a°

Misalign. Angle

Ultimate

Radial

Static

Load

Capacity

Newtons

Approx.

 Brg. Wt.

 Grams

Right

Hand

Left

Hand†

B

+ .065

- .013

W

± .13

H

Ref.

A

± .40

D

Ref.

K

± .25

J

± .25

Ball Dia.

 Ref.

C

± 1.00

Thread

a1

a3

a4

CW-M3

CG-M3

3

6

4.25

21

12.50

8

7

7.93

10

M3 X 0.5

23

34

71

5,746

10

CW-M5

CG-M5

5

8

5.75

27

16.00

11

9

11.10

14

M5 X 0.8

22

30

64

8,247

18

CW-M6

CG-M6

6

9

6.25

30

19.00

13

11

12.70

14

M6 X 1.0

23

31

65

11,895

25

CW-M8

CG-M8

8

12

8.00

36

22.25

16

14

15.88

17

M8 X 1.25

28

38

59

15,190

40

CW-M10

CG-M10

10

14

9.50

43

27.00

19

17

19.05

21

M10 X 1.5

26

35

57

22,750

80

CW-M12

CG-M12

12

16

10.75

50

30.00

22

19

22.23

24

M12 X 1.75

27

34

57

25,819

95

CW-M14

CG-M14

14

19

12.25

57

34.75

25

22

25.40

27

M14 X 2.0

30

39

55

35,214

160

CW-M16

CG-M16

16

21

12.75

64

38.00

27

22

28.58

33

M16 X 2.0

33

42

59

37,391

215

CW-M18

CG-M18

18

23

14.75

71

42.00

31

27

31.75

36

M18 X 1.5

30

37

56

47,903

300

CW-M20

CG-M20

20

25

16.25

77

46.00

34

30

34.93

40

M20 X 1.5

29

36

55

57,101

350
