PNB-3TG、PNB-4TG、PNB-5TG、PNB-6TG、PNB-7TG、PNB-8TG、PNB-9TG、PNB-10TG关节

BEARING NO.

DIMENSIONS IN INCHES

Static Limit Load

No Load

a°

Rotational

Approx.

Grooved

Plain

B

+ .0000

- .0005

D

+ .0000

- .0005

W

+ .000

- .005

H

± .005

O

Min.

P

+ .000

- .010

S

Min.

G

+ .000

- .008

R

+ .002

- .005

Ball Dia.

Ref.

Misalign.

Angle

Radial

Lbs.

Axial

Lbs.

Breakaway

Torque In.-

Lbs.

Brg.

Wt. Lbs.

PNB-3TG

PNB-3T

.1900

.5625

.281

.218

.293

.025

.010

.500

.010

.406

10

3,975

150

0.25 - 5.0

.02

PNB-4TG

PNB-4T

.2500

.6562

.343

.250

.364

.025

.010

.594

.010

.500

10

6,040

430

0.25 - 5.0

.02

PNB-5TG

PNB-5T

.3125

.7500

.375

.281

.419

.035

.020

.650

.010

.562

10

8,750

700

0.25 - 8.0

.03

PNB-6TG

PNB-6T

.3750

.8125

.406

.312

.475

.035

.020

.712

.015

.625

9

10,540

1,100

0.25 - 8.0

.04

PNB-7TG

PNB-7T

.4375

.9062

.437

.343

.530

.035

.020

.806

.015

.687

8

13,200

1,400

0.25 - 8.0

.05

PNB-8TG

PNB-8T

.5000

1.0000

.500

.390

.600

.055

.020

.876

.015

.781

8

17,900

2,100

0.25 - 8.0

.07

PNB-9TG

PNB-9T

.5625

1.0937

.562

.437

.670

.060

.020

.972

.015

.875

8

23,200

3,680

0.25 - 8.0

.09

PNB-10TG

PNB-10T

.6250

1.1875

.625

.500

.739

.055

.020

1.063

.015

.968

8

30,500

4,720

0.25 - 8.0

.12

PNB-12TG

PNB-12T

.7500

1.4375

.750

.593

.920

.055

.020

1.313

.015

1.187

8

46,400

6,750

0.25 - 8.0

.21
