ROD END NO.

DIMENSIONS IN INCHES

a°

Misalign.

 Angle

Ultimate Radial

Static Load

Capacity Lbs.

Approx.

Brg. Wt.

 Lbs.

Right

Hand

Left

Hand†

B

+ .0015

-.0005

W

+ .000

- .005

H

± .005

A

± .015

D

± .010

K

± .010

J

± .010

Ball Dia

. Ref.

C

+ .062

- .031

Thread

UNF-2B

KW-3

KG-3

.1900

.312

.250

1.062

.625

.406

.312

.437

.562

10-32

13

1,531

.04

KW-4

KG-4

.2500

.375

.281

1.312

.750

.469

.375

.500

.750

1/4-28

16

2,539

.06

KW-5

KG-5

.3125

.437

.344

1.375

.875

.500

.437

.625

.750

5/16-24

14

3,133

.09

KW-6

KG-6

.3750

.500

.406

1.625

1.000

.687

.562

.719

.937

3/8-24

12

3,915

.15

KW-7

KG-7

.4375

.562

.437

1.812

1.125

.750

.625

.812

1.062

7/16-20

14

4,218

.20

KW-8

KG-8

.5000

.625

.500

2.125

1.312

.875

.750

.937

1.187

1/2-20

12

6,660

.33

KW-10

KG-10

.6250

.750

.562

2.500

1.500

1.000

.875

1.125

1.500

5/8-18

16

7,364

.48

KW-12

KG-12

.7500

.875

.687

2.875

1.750

1.125

1.000

1.312

1.750

3/4-16

14

11,518

.72

KW-14

KG-14

.8750

.875

.765

3.375

2.000

1.300

1.125

1.375

1.875

7/8-14

7

18,476

1.03

KW-16

KG-16

1.0000

1.375

1.000

4.125

2.750

1.625

1.500

1.875

2.125

1 1/4-12

17

40,889

2.13

KW-16-1

KG-16-1

1.0000

1.375

1.000

4.125

2.750

1.625

1.500

1.875

2.125

1-143

17

43,541

2.41

KW-16-2

KG-16-2

1.0000

1.375

1.000

4.125

2.750

1.625

1.500

1.875

2.125

1-12

17

43,541

2.41

ROD END NO.

DIMENSIONS IN MILLIMETERS

a°

Misalign

. Angle

Ultimate Radial

Static Load

Capacity

Newtons

Approx.

Brg. Wt.

 Grams

Right

Hand

Left

Hand†

B

+ .038

- .013

W

+ .00

- .13

H

± .13

A

± .38

D

± .25

K

± .25

J

± .25

Ball Dia.

 Ref.

C

+ 1.57

- .79

Thread

UNF-2B

KW-3

KG-3

4.826

7.92

6.35

26.97

15.88

10.31

7.92

11.10

14.27

10-32

13

6,805

17

KW-4

KG-4

6.350

9.53

7.14

33.32

19.05

11.91

9.53

12.70

19.05

1/4-28

16

11,297

27

KW-5

KG-5

7.938

11.10

8.74

34.93

22.23

12.70

11.10

15.88

19.05

5/16-24

14

13,934

42

KW-6

KG-6

9.525

12.70

10.31

41.28

25.40

17.45

14.27

18.26

23.80

3/8-24

12

17,416

69

KW-7

KG-7

11.113

14.27

11.10

46.02

28.58

19.05

15.88

20.62

26.97

7/16-20

14

18,759

90

KW-8

KG-8

12.700

15.88

12.70

53.98

33.32

22.23

19.05

23.80

30.15

1/2-20

12

29,624

149

KW-10

KG-10

15.875

19.05

14.27

63.50

38.10

25.40

22.23

28.58

38.10

5/8-18

16

32,752

216

KW-12

KG-12

19.050

22.23

17.45

73.03

44.45

28.58

25.40

33.32

44.45

3/4-16

14

51,237

328

KW-14

KG-14

22.225

22.23

19.43

85.73

50.80

33.02

28.58

34.93

47.63

7/8-14

7

82,185

467

KW-16

KG-16

25.400

34.93

25.40

104.78

69.85

41.28

38.10

47.63

53.98

1 1/4-12

17

181,874

964

KW-16-1

KG-16-1

25.400

34.93

25.40

104.78

69.85

41.28

38.10

47.63

53.98

1-143

17

193,670

1,093

KW-16-2

KG-16-2

25.400

34.93

25.40

104.78

69.85

41.28

38.10

47.63

53.98

1-12

17

193,670

1,093
