ROD END NO.

DIMENSIONS IN INCHES

a°

Misalign.

 Angle

Ultimate Radial

Static Load

Capacity Lbs.

Approx.

Brg. Wt.

Lbs.

Right

Hand

Left

Hand

B

+ .0025

- .0005

W

+ .005

H

Ref.

A

± .015

D

Ref.

Ball Dia.

 Ref.

C

+ .062

- .031

Thread

UNF-3A

VCAM-5

VCAB-5

.3125

.437

.312

1.875

.875

.593

1.250

5/16-24

18

5,032

.07

VCAM-6

VCAB-6

.3750

.500

.359

1.938

1.000

.687

1.250

3/8-24

18

6,533

.11

VCAM-7

VCAB-7

.4375

.562

.406

2.125

1.125

.781

1.375

7/16-20

17

8,054

.15

VCAM-8

VCAB-8

.5000

.625

.453

2.438

1.312

.875

1.500

1/2-20

16

13,425

.24

VCAM-10

VCAB-10

.6250

.750

.484

2.625

1.500

1.062

1.625

5/8-18

22

14,755

.36

VCAM-12

VCAB-12

.7500

.875

.593

2.875

1.750

1.250

1.750

3/4-16

20

21,150

.57

ROD END NO.

DIMENSIONS IN MILLIMETERS

a°

Misalign

. Angle

Ultimate Radial

Static Load

Capacity

Newtons

Approx. Brg.

Wt. Grams

Right

Hand

Left

Hand

B

+ .064

- .013

W

+ .13

H

Ref.

A

+ .38

D

Ref.

Ball Dia.

 Ref.

C

+ 1.57

- .79

Thread

UNF-3A

VCAM-5

VCAB-5

7.938

11.10

7.92

47.63

22.23

15.06

31.75

5/16-24

18

22,382

32

VCAM-6

VCAB-6

9.525

12.70

9.12

49.23

25.40

17.45

31.75

3/8-24

18

29,059

50

VCAM-7

VCAB-7

11.113

14.27

10.31

53.98

28.58

19.84

34.93

7/16-20

17

35,824

68

VCAM-8

VCAB-8

12.700

15.88

11.50

61.93

33.32

22.23

38.10

1/2-20

16

59,714

109

VCAM-10

VCAB-10

15.875

19.05

12.29

66.68

38.10

26.97

41.28

5/8-18

22

65,630

163

VCAM-12

VCAB-12

19.050

22.23

15.06

73.03

44.45

31.75

44.45

3/4-16

20

94,075

259
