Shaft Size

Part No.

Description

Wt.

Used on Frame

A

B

C

D

Min.

Max.

1-15/16

230050

P4B-BAA-115

11

HD-200

4

8-1/4

3-1/2

6-5/16

6-11/16

2-3/16

230053

P4B-BAA-203

14

HD-200

4-1/2

8-1/2

3-1/2

6-9/16

6-15/16

2-7/16

230056

P4B-BAA-207

20

HD-200

5

10-1/4

4

7-11/16

8-5/16

2-11/16

230059

P4B-BAA-211

24

HB-250

5-1/2

10-1/2

4-1/4

7-15/16

8-9/16

2-15/16

230062

P4B-BAA-215

28

HD-250

6

11

4-1/2

8-7/16

9-1/16

3-7/16

230065

P4B-BAA-307

47

HD-300

7

13

5

10-1/16

10-15/16

3-15/16

230068

P4B-BAA-315

61

HD-350

8

14-3/4

5-1/2

11-7/16

12-9/16

4-7/16

230071

P4B-BAA-407

84

HD-400

9

16-9/16

6-5/16

12-15/16

14-1/16

4-15/16

230074

P4B-BAA-415

112

HD-400

10

18

7

14-5/16

15-11/16

5-7/16

230077

P4B-BAA-507

154

HD-500

11

19-3/4

8

15-1/16

16-7/16

5-15/16

230080

P4B-BAA-515

184

HD-500

12

20-1/2

8-1/2

15-13/16

17-3/16

6-1/2

230134

P4B-BAA-608

220

...

13

22

9-5/8

17-3/16

18-13/16

7

230137

P4B-BAA-700

275

...

14

23

10

18-1/4

19-3/4

8

230140

P4B-BAA-800

400

...

16

26

11

20-11/16

22-5/16

Shaft Size

E

F

Bolt

G

H

J

M

Grease Cups #

Pipe Tap

No. Reqd

Size

1-15/16

1-3/4

1/2

3/4

7/8

4-11/16

2-1/4

1/4

1

1

2-3/16

1-3/4

1/2

3/4

1

5-1/8

2-1/2

3/8

1

2

2-7/16

2

5/8

1

1-1/8

5-9/16

2-3/4

3/8

1

2

2-11/16

2-1/4

5/8

1

1-1/4

5-7/8

3

3/8

1

2

2-15/16

2-1/2

5/8

1

1-3/8

6-3/8

3-1/4

3/8

1

2

3-7/16

2-3/4

3/4

1-1/4

1-1/2

7-1/8

3-1/2

1/2

1

3

3-15/16

3

3/4

1-3/8

1-21/32

7-1/2

3-3/4

1/2

1

4

4-7/16

3-1/2

7/8

1-1/2

1-3/4

8-1/2

4-1/8

1/2

1

4

4-15/16

4

7/8

1-5/8

1-7/8

9-3/16

4-1/2

1/2

1

4

5-7/16

4-1/2

1-1/8

1-7/8

2

10-1/4

5

1/2

2

3

5-15/16

5

1-1/8

1-7/8

2-1/8

11-1/16

5-1/2

1/2

2

3

6-1/2

5-1/2

1-1/8

2

2-1/4

12-1/8

6

1/2

2

4

7

6

1-1/8

2

2-3/8

13

6-1/2

1/2

2

4

8

6-3/4

1-3/8

2-1/4

2-1/2

14-1/16

7

1/2

2

4
