Bearing

Shaft Size Inch

TRIDENT Seal

Labyrinth Seal

Non-Expansion

Expansion

Non-Expansion

Expansion

Part No.

Part Name

Part No.

Part Name

Part No.

Part Name

Part No.

Part Name

22215

2-11/16

069822

FC-IP-211R

069854

FC-IP-211RE

069886

FC-IP-211L

069918

FC-IP-211LE

2-3/4

069823

FC-IP-212R

069855

FC-IP-212RE

069887

FC-IP-212L

069919

FC-IP-212LE

2-15/16

069824

FC-IP-215R

069856

FC-IP-215RE

069888

FC-IP-215L

069920

FC-IP-215LE

3

069825

FC-IP-300R

069857

FC-IP-300RE

069889

FC-IP-300L

069921

FC-IP-300LE

22218

3-3/16

069826

FC-IP-303R

069858

FC-IP-303RE

069890

FC-IP-303L

069922

FC-IP-303LE

3-1/4

069827

FC-IP-304R

069859

FC-IP-304RE

069891

FC-IP-304L

069923

FC-IP-304LE

3-7/16

069828

FC-IP-307R

069860

FC-IP-307RE

069892

FC-IP-307L

069924

FC-IP-307LE

3-1/2

069829

FC-IP-308R

069861

FC-IP-308RE

069893

FC-IP-308L

069925

FC-IP-308LE

22220

3-11/16

069830

FC-IP-311R

069862

FC-IP-311RE

069894

FC-IP-311L

069926

FC-IP-311LE

3-15/16

069831

FC-IP-315R

069863

FC-IP-315RE

069895

FC-IP-315L

069927

FC-IP-315LE

4

069832

FC-IP-400R

069864

FC-IP-400RE

069896

FC-IP-400L

069928

FC-IP-400LE

22222

4-7/16 4-1/2

069833 069834

FC-IP-407R FC-IP-408R

069865 069866

FC-IP-407RE FC-IP-408RE

069897 069898

FC-IP-407L FC-IP-408L

069929 069930

FC-IP-407LE FC-IP-408LE

22226

4-15/16 5

069835 069836

FC-IP-415R FC-IP-500R

069867 069868

FC-IP-415RE FC-IP-500RE

069899 069900

FC-IP-415L FC-IP-500L

069931 069932

FC-IP-415LE FC-IP-500LE

SHAFT SIZE

A

B

C

D

DD

E

F BOLT DIA.

G

H

K*

L

M

N

P

Q

X TOTAL EXP

2-11/16 2-3/4 2-15/16 3

3-1/2

8-3/4

2-5/8

5-19/64

7-1/2

1-1/4

5/8

1-15/16

3/4

6.375

4-9/32

5/8 - 11

3-9/16

1-9/16

1-5/8

1/4

3-3/16 3-1/4 3-7/16 3-1/2

4-11/64

10 1/4

3

6-3/32

8-5/8

1-17/64

3/4

2-17/32

15/16

7.375

5

3/4 - 10

4-1/16

1-41/64

1-33/64

1/4

3-11/16 3-15/16 4

4-45/64

10-7/8

3-1/2

6-5/8

9-3/8

1-15/32

3/4

2-57/64

1-1/8

8.125

5-9/16

3/4 - 10

4-25/32

1-13/16

1-29/32

5/16

4-7/16 4 1/2

5-15/64

13-1/2

4

5-7/8

11-3/4

1-29/64

3/4**

3-9/16

1

10.250

6-7/16

3/4 - 10

5-35/64

1-43/64

1-63/64

3/8

4-15/16 5

5-63/64

14-3/4

4-3/8

6-3/8

12-3/4

1-45/64

7/8**

3-55/64

1-1/4

11.000

7-5/8

3/4 - 10

6-9/32

2-1/8

2-27/64

3/8
