WSTU-S2-107R、WSTU-S2-112R

Bearing

Shaft Size

Inch

Take-Up

Frame

TRIDENT Seal

Non-Expansion

 Expansion

Part No.

 Part Name

Part No.

 Part Name

22208

1-3/8

CP-308

070752

WSTU-S2-106R

070779

WSTU-S2-106RE

1-7/16

070753

WSTU-S2-107R

070780

WSTU-S2-107RE

1-1/2

070754

WSTU-S2-108R

070781

WSTU-S2-108RE

22209

1-11/16

1-3/4

CP-400

070756

070757

WSTU-S2-111R

WSTU-S2-112R

070783

070784

WSTU-S2-111RE

WSTU-S2-112RE

22210

1-15/16

2

CP-400

070758

070759

WSTU-S2-115R

WSTU-S2-200R

070785

070786

WSTU-S2-115RE

WSTU-S2-200RE

22211

2-3/16

CP-408

070760

WSTU-S2-203R

070787

WSTU-S2-203RE

SHAFT SIZE

A

B

C

D

E

F

G

H

J

1-3/8

1-7/16

1-1/2

2-17/32

5-1/16

17/32

2-3/4

3-3/16

7/8

11/16

5/8

2-7/16

1-11/16

1-3/4

2-43/64

5-15/16

11/16

3-1/8

3-13/16

1-1/8

15/16

3/4

3-5/16

1-15/16

2

2-27/32

6-3/16

11/16

3-5/8

3-15/16

1-1/8

15/16

3/4

3-5/16

2-3/16

2-15/16

7-1/16

13/16

3-5/8

4-5/8

1-3/8

15/16

1-1/4

3-7/8

SHAFT SIZE

K

L

M

N

R

S

T

X

1-3/8

1-7/16

1-1/2

1-7/16

2-3/4

3-1/2

4-1/8

2-47/64

1-45/64

2-1/16

3/16

1-11/16

1-3/4

1-15/16

3-3/16

4

4-3/4

2-53/64

1-13/16

2-1/32

1/4

1-15/16

2

1-15/16

3-7/16

4

4-3/4

2-15/16

1-15/16

2

1/4

2-3/16

2-1/4

3-3/4

4-1/2

5-1/4

3-3/32

1-63/64

2-7/32

1/4
