SHAFT SIZE RANGE SYMBOL#

PART NUMBER

PART NAME

WEIGHT LBS (APPROX)

106 TO 108

067007*

HS2-HC-406

13

111 TO 112

067100*

HS2-HC-444

16

115 TO 200

067031*

HS2-HC-481

23

203

067120*

HS2-HC-538

26

207

067135*

HS2-HC-569

40

215

067078*

HS2-HC-656

52

SHAFT SIZE

 INCHES

A

B

C

D

F DIA

BOLT

H

J

L

M

N

R

S

1-3/8

1-7/16

1-1/2

4-1/8

7-1/4

3

5-7/8

1/2

3/4

6-7/8

2-7/16

2-7/8

3-1/4

1-15/16

2-3/16

1-11/16

1-3/4

4-1/4

8-1/4

3-1/4

6-7/8

1/2

3/4

6-7/8

2-13/16

3-1/8

3-17/32

2

2-1/4

1-15/16

2

4-7/16

9-1/4

3-1/2

7-11/16

5/8

7/8

7-5/8

3-1/16

3-1/4

3-13/16

2-1/8

2-5/16

2-3/16

4-3/4

10-1/4

4

8-1/4

3/4

1

7-5/8

3-7/16

3-3/4

4-7/32

2-1/4

2-1/2

2-7/16

5-5/16

10-1/4

4-1/4

8-1/4

3/4

1

9-5/8

3-13/16

4-1/2

4-5/8

2-9/16

2-3/4

2-15/16

6-1/16

11-1/8

4-3/4

9-1/8

3/4

1-1/4

10-1/8

4-7/16

5

5-1/4

2-15/16

3-1/8
