S1U516-TAF-212

SHAFT

SIZE # INCHES

PART NUMBER

PART NAME

WEIGHT

LBS (APPROX)

1-7/16

037632

S1U509-TAF-107

5

1-11/16

037633

S1U510-TAF-111

7

1-15/16

037634

S1U511-TAF-115

8

2-3/16

037635

S1U513-TAF-203

9

2-7/16

037636

S1U515-TAF-207

11

2- 1/2

037637

S1U515-TAF-208

11

2-11/16

037638

S1U516-TAF-211

18

2-3/4

037639

S1U516-TAF-212

17

2-15/16

037640

S1U517-TAF-215

17

3

037641

S1U517-TAF-300

17

3-7/16

037642

S1U520-TAF-307

31

3-1/2

037643

S1U520-TAF-307

31

3-15/16

037644

S1U522-TAF-315

43

4

037645

S1U522-TAF-400

43

4-7/16

037646

S1U526-TAF-407

57

4-1/2

037647

S1U526-TAF-408

68

4-15/16

037648

S1U528-TAF-415

82

5

037649

S1U528-TAF-500

82

5-7/16

023610

S1U-TAF-507R

155

5-15/16

023611

S1U-TAF-515R

143

6

023612

S1U-TAF-600R

138

6-7/16

023613

S1U-TAF-607R

187

6-1/2

023614

S1U-TAF-608R

182

6-15/16

023615

S1U-TAF-615R

180

7

023616

S1U-TAF-700R

178

SHAFT

SIZE INCHES

A

B

C

E

MACH.              CAST

SIDE                SIDE

H

K

L

M

1-7/16

3

2-1/16

1-5/32

3.250

3.31

3/4

3.595 •

2-3/4

2-1/2

1-11/16

3-3/8

2-5/16

1-3/16

3.750

3.81

3/4

4.095 •

3-3/16

2-7/8

1-15/16

3-1/2

2-7/16

1-1/2

4.125

4.18

3/4

4.502 •

3-7/16

2-3/4

2-3/16

3-3/4

2-9/16

1-9/16

4.500

4.56

3/4

4.940 •

3-3/4

2-61/64

2-7/16

2- 1/2

4

2-3/4

1-7/16

4.812

4.87

3/4

5.156 •

4-1/16

3-3/8

2-15/16

3

4-1/2

3

1-7/8

5.563

5.63

3/4

6.001 •

4-23/32

3-7/8

3-7/16

3-1/2

5

3-1/2

2-3/16

6.813

6.88

3/4

7.313*

5-1/2

4-1/2

3-15/16

4

6-1/4

4-1/2

2-19/32

7.438

7.40

15/16

7.937*

6

5-1/8

4-7/16

4-1/2

6-3/4

4-5/8

2-9/16

8.313

8.32

15/16

8.812*

6-29/64

5-1/2

4-15/16

5

7-1/4

5-1/8

3-1/8

9.563

9.54

15/16

10.124*

7-29/64

6-3/16

5-7/16

5-15/16

6

9

5-7/8

2-9/16

11.190

11.19

15/16

11.563 ^

9-3/8

6-29/32

6-7/16

6-1/2

6-15/16

7

10-1/2

7-1/8

3

13.250

13.25

15/16

13.748 ^

11-3/8

8
