型号

SHAFT SIZE

INCHES

A

B

C

D

E

F

Bolt

Dia.

G

H

J

L

F4B-DI-107R

1-7/16

3

5-3/4

2-1/8

6-1/4

5/16

1/2

5-3/4

1/2

4-27/64

2-3/4

F4B-DI-115R

1-15/16

3-1/2

6-7/8

2-9/16

7-1/2

3/8

5/8

7-1/4

9/16

5-5/16

3-7/16

F4B-DI-200R

2

F4B-DI-203R

2-3/16

3-3/4

7-3/16

2-23/32

8

7/16

5/8

7-13/16

9/16

5-21/32

3-3/4

F4B-DI-207R

2-7/16

4

7-5/8

2-15/16

8-1/2

7/16

5/8

8-9/16

5/8

6

4-1/16

F4B-DI-208R

2-1/2

F4B-DI-215R

2-15/16

4-1/2

8-7/8

3-11/32

9-3/4

1/2

3/4

9-1/2

11/16

6-57/64

4-23/32

F4B-DI-300R

3

F4B-DI-307R

3-7/16

5

10-1/4

3-23/32

11-1/2

1/2

7/8

11-3/8

3/4

8-1/8

5-1/2

F4B-DI-315R

3-15/16

6-1/4

11-7/16

4-5/8

13

3/4

1

12-7/8

13/16

9-3/16

6

F4B-DI-407R

4-7/16

6-3/4

17-3/4

4-5/8

15

1-1/16

1

-----

1

10-39/64

6-29/64

F4B-DI-408R

4-1/2

F4B-DI-415R

4-15/16

7-1/4

19

5

16

1-1/8

1-1/8

-----

1-1/8

11-5/16

7-29/64
