P4B-E-207R、P4B-E-212R

型号

SHAFT SIZE

INCHES

A

B

C*

D

E

F BOLT

 DIA

G

H

J1

J

L

M

MIN

MAX

P4B-E-204R

2-1/4

4

10-1/2

3-1/2

8-5/16

8-11/16

1-7/8

5/8

7/8

1-5/8

5-1/2

5-5/8

4-1/16

2-3/4

P4B-E-207R

2-7/16

P4B-E-208R

2-1/2

P4B-E-211R

2-11/16

4-1/2

12

4

9-3/16

9-13/16

2-1/8

5/8

1

1-7/8

6-1/4

6-11/32

4-23/32

3-1/8

P4B-E-212R

2-3/4

P4B-E-215R

2-15/16

P4B-E-300R

3

P4B-E-303R

3-3/16

5

13-1/2

4-1/2

10-3/4

11-1/4

2-3/8

3/4

1-3/16

2-1/4

7-1/2

7-1/2

5-1/2

3-3/4

P4B-E-304R

3-1/4

P4B-E-307R

3-7/16

P4B-E-308R

3-1/2

P4B-E-315R

3-15/16

6-1/4

15-1/4

4-1/2

12-1/4

12-3/4

2-1/4

3/4

1-1/8

2-7/16

8-1/2

8-7/16

6

4-1/4

P4B-E-400R

4

P4B-E-407R

4-7/16

6-3/4

16-5/8

4-5/8

13-1/4

13-3/4

2-1/2

3/4

1-1/8

2-3/4

9-3/8

9-9/32

6-29/64

4-3/4

P4B-E-408R

4-1/2

P4B-E-415R

4-15/16

7-1/4

18-1/2

5-1/8

15-1/4

15-3/4

2-7/8

7/8

1-1/4

3

10-7/8

10-11/16

7-29/64

5-1/2

P4B-E-500R

5

P4B-E-507R

5-7/16

9

22

6-1/4

17-3/8

19-1/8

3-3/4

1

2

3-1/4

13-3/16

----

9-3/8

6-11/16

P4B-E-515R

5-15/16

P4B-E-600R

6

P4B-E-607R

6-7/16

10-1/2

26

7-1/8

21-1/4

23-1/4

4-5/8

1

2

3-11/16

14-15/16

----

11-3/8

7-1/2

P4B-E-608R

7
