Series

Shaft Size

Part No.

Description

204

3/4

128796

FB-DL-012

205

7/8

128797

FB-DL-014

15/16

128798

FB-DL-015

1

128799

FB-DL-100

206

1-1/8

128800

FB-DL-102

1-3/16

128801

FB-DL-103

1-1/4

128802

FB-DL-104S

207

1-1/4

128803

FB-DL-104

1-3/8

128804

FB-DL-106

1-7/16

128805

FB-DL-107

208

1-15/16

2

128806

128807

FB-DL-115

FB-DL-200

Series

Shaft Size

Weight

lbs

A

B

C

D

E

F

Bolt Dia.

G

H

I

J

K

L

M

204

3/4

0.80

1-9/32

4-1/4

1-11/32

1-1/2

1-11/16

3/8

7/8

5/16

3

2-1/2

63/64

1-45/64

2-3/8

205

7/8

0.95

1-7/16

4-3/4

1-1/2

1-5/8

1-13/16

3/8

1-1/8

3/8

3-3/8

2-3/4

1-7/64

2

2-1/2

15/16

0.90

1

0.85

206

1-1/8

1.50

1-9/16

5-3/8

1-5/8

1-7/8

2-1/16

3/8

1-1/4

3/8

3-3/4

3-1/4

1-1/8

2-7/32

2-3/4

1-3/16

1.45

1-1/4

1.40

207

1-1/4

1.85

1-3/4

6-1/8

1-7/8

2

2-3/8

1/2

1-1/4

1/2

4-1/4

3-3/4

1-5/16

2-11/16

3-1/4

1-3/8

1.80

1-7/16

1.75

210

1-15/16

2

5.7

5.6

2-3/32

7-1/2

2-1/32

2-3/4

2-15/16

1/2

1-5/8

1/2

5-3/16

4-5/8

1-1/2

3-15/64

4
