Series

Shaft Size

Complete Unit

Unit Without Adapter & Nut

Adapter & Nut Assembly

Part No.

Description

Part No.

Description

Part No.

Description

210

1-11/16 1 -3/4

136186 136187

TP-GTM 111  TP-GTM-112

136231

TP-GT-10

129929 129930

AN-GTM-10-111  AN-GTM-10-112

211

1-15/16 2

136188 136189

TP-GTM 115  TP-GTM-200

136232

TP-GT-11

129931 129932

AN-GTM-11-115  AN-GTM-11-200

212

2 -3/16 2-1/4

136190 136191

TP-GTM-203  TP-GTM-204

136233

TP-GT-12

129933 129934

AN-GTM-12-203  AN-GTM-12-204

214

2-7/16 2-1/2

136192 136193

TP-GTM-207  TP-GTM-208

136234

TP-GT-14

129935 129936

AN-GTM-14-207  AN-GTM-14-208

215

2-11/16

136194

TP-GM-211

136235

TP-GT-15

129937

AN-GTM-15-211

216

2 -5/16 3

136195 136196

TP-GTM 215  TP-GTM-300

136236

TP-GT-16

129938 129939

AN-GTM-16-215  AN-GTM-16-300

218

3-7/16 3-1/2

136197 136198

TP-GTM-307  TP-GTM-308

136237

TP-GT-18

129940 129941

AN-GTM-18-307  AN-GTM-18-308

Series

Shaft Size

Weight lbs

Take-Up Frame

A

B

C

D

E

J

L

R#

S#

T

Z

210

1-11/16 1 -3/4

11.6 11.2

TP10

1-55/64

6-1/2

2-3/8

6

3-1/4

6-3/8

3-1/8

21/32

1-13/64

2-3/8

1-9/32

211

1-15/16 2

14.0 13.7

TP20

1-59/64

7

2-1/2

6-3/4

3-3/8

6-7/8

3-27/64

45/64

1-7/32

2-3/8

1-11/32

212

2 -3/16 2-1/4

17.4 17.2

TP30

2-7/64

7-1/2

2-3/4

7

3-1/2

7-7/16

3-11/16

49/64

1-11/32

2-3/4

1-15/32

214

2-7/16 2-1/2

22.9 22.5

TP40

2-25/64

8-1/2

2-1/2

8

4

8-5/16

4

7/8

1-33/64

2-3/4

1-19/32

215

2-11/16

26.2

TP40

2-29/64

8-1/2

2-1/2

8

4

8-5/16

4-7/16

57/64

1-43/64

2-3/4

1-5/8

216

2 -15/16 3

31.0 30.7

TP50

2-11/16

9-1/2

2-3/4

9

4-1/2

9-5/8

4-11/16

29/32

1-55/64

3-1/8

1-5/8

218

3-7/16 3-1/2

41.4 41.1

TP50

2-51/64

11

3-1/8

10-1/2

5-1/2

11

5-3/16

1

1-51/64

3-1/8

1-45/64
