WSTU-GT-111、WSTU-GT-45M

Series

Shaft Size

Complete Unit Part No.   Description

Unit without Adapter Sleeve & Lock Nut Part  No.                 Description

Adapter Sleeve & Lock Nut Assembly Part No.                 Description

209

1-5/8

136142

WSTU-GT-110L

136224

WSTU-GT-09

129915

AN-GT-09-110

1-11/16

136143

WSTU-GT-111

129916

AN-GT-09-111

1-3/4

136144

WSTU-GT-112

129917

AN-GT-09-112

45mm

136252

WSTU-GT-45M

129948

AN-GT-09-45M

210

1-15/16

136145

WSTU-GT-115

136225

WSTU-GT-10

129918

AN-GT-10-115

2

136146

WSTU-GT-200

129919

AN-GT-10-200

50mm

136253

WSTU-GT-50M

129949

AN-GT-10-50M

211

2

136178

WSTU-GTM-200

136226

WSTU-GT-11

129932

AN-GTM-11-200

2-3/16

136147

WSTU-GT-203

129920

AN-GT-11-203

2-1/4

136148

WSTU-GT-204

129956

AN-GT-11-204

55mm

136254

WSTU-GT-55M

129950

AN-GT-11-55M

212

2-1/4

136180

WSTU-GTM-204

136227

WSTU-GT-12

129934

AN-GTM-12-204

2-7/16

136149

WSTU-GT-207

129921

AN-GT-12-207

60mm

136255

WSTU-GT-60M

129951

AN-GT-12-60M

214

2-1/2

136182

WSTU-GTM-208

136228

WSTU-GT-14

129936

AN-GTM-14-208

2-11/16

136150

WSTU-GT-211

129922

AN-GT-14-211

70mm

163256

WSTU-GT-70M

129952

AN-GT-14-70M

215

2-15/16

136151

WSTU-GT-215

136229

WSTU-GT-15

129923

AN-GT-15-215

3

@

WSTU-GT-300

129887

AN-GT-15-300

75mm

136257

WSTU-GT-75M

129953

AN-GT-15-75M

Series

Shaft Size

Wgt. lbs

Take- Up Frame

A

B

C*

D

E

F Screw

G

H

J

K

L

M*

N

R#

S#

T

Z

209

1-5/8

6.1

WS400

1-55/64

5-5/8

11/16

3-1/4

3-7/16

1

5/8

3/4

3-1/4

1-15/16

2-55/64

4

4-3/4

21/32

1-3/16

1-15/16

1-9/32

1-11/16 1-3/4

6.0 5.9

45mm

2.7

47.2

142.9

17.5

82.6

87.3

25.4

15.9

19.1

82.6

49.2

72.6

101.6

120.7

16.7

30.2

49.2

32.6

210

1-15/16 2 50mm

6.4 6.3 2.9

WS400

1-55/64 47.2

5-13/16 147.6

11/16 17.5

3-3/8 85.7

3-9/16 90.5

1 25.4

5/8 15.9

3/4 19.1

3-1/4 82.6

1-15/16 49.2

3-1/8 79.4

4 101.6

4-3/4 120.7

21/32 16.7

1-13/64 30.6

1-15/16 49.2

1-9/32 32.6

211

2 2-3/16 2-1/4 55mm

10.1 10.0 9.9 4.5

WS502

1-59/64 48.8

6-11/16 169.9

1-1/16 27.0

3-3/4 95.3

4-3/16 106.4

1-1/4 31.8

3/4 19.1

1 25.4

4 101.6

2-1/2 63.5

3-27/64 86.9

5-1/8 130.2

5-7/8 149.2

45/64 17.9

1-7/32 31.0

2-1/2 63.5

1-11/32 34.0

212

2-1/4 2-7/16 60mm

11.2 10.8 4.9

WS502

2-7/64 53.6

7-1/2 190.5

1-1/16 27.0

4 101.6

4-11/16 119.1

1-1/4 31.8

3/4 19.1

1-1/4 31.8

4 101.6

2-1/2 63.5

3-11/16 93.7

5-1/8 130.2

5-7/8 149.2

49/64 19.4

1-11/32 34.1

2-1/2 63.5

1-15/32 37.1

214

2-1/2 2-11/16 70mm

18.0 17.8 8.2

WS515

2-25/64 60.7

8-9/16 217.5

1-1/16 27.0

4-3/4 120.7

5-3/8 136.5

1-1/2 38.1

13/16 20.6

1-1/4 31.8

4-3/8 111.1

2-3/4 69.9

4 101.6

5-15/16 150.8

6-9/16 166.7

7/8 22.2

1-33/64 38.5

2-3/4 69.9

1-19/32 40.5

215

2-15/16 3 75mm

18.9 18.7 8.6

WS515

2-29/64 62.3

9-1/8 231.8

1-1/16 27.0

4-3/4 120.7

5-1/2 139.7

1-1/2 38.1

13/16 20.6

1-1/4 31.8

4-3/8 111.1

2-3/4 69.9

4-7/16 112.7

5-15/16 150.8

6-11/16 169.9

57/64 22.6

1-43/64 42.5

2-3/4 69.9

1-5/8 41.3
