Series

Shaft Size

Complete Unit Part No.      Description

Unit without Adapter  Sleeve & Lock Nut Part No.           Description

Adapter Sleeve & Lock Nut Assembly Part No.    Description

211

1-15/16

129700

F4B-GTMAH-115

129482

F4B-GTAH-11

129931

AN-GTM-11-115

2

@

F4B-GTMAH-200

129932

AN-GTM-11-200

50mm

@

F4B-GTMAH-50M

129961

AN-GTM-11-50M

212

2-3/16

129701

F4B-GTMAH-203

129483

F4B-GTAH-12

129933

AN-GTM-12-203

2-1/4

@

F4B-GTMAH-204

129934

AN-GTM-12-204

55mm

@

F4B-GTMAH-55M

129962

AN-GTM-12-55M

214

2-7/16

129702

F4B-GTMAH-207

129484

F4B-GTAH-14

129935

AN-GTM-14-207

2-1/2

@

F4B-GTMAH-208

129936

AN-GTM-14-208

65mm

@

F4B-GTMAH-65M

129963

AN-GTM-14-65M

215

2-11/16 70mm

@ @

F4B-GTMAH-211 F4B-GTMAH-70M

129485

F4B-GTAH-15

129937 129964

AN-GTM-11-211 AN-GTM-11-70M

216

2-15/16

129703

F4B-GTMAH-215

129488

F4B-GTAH-16

129938

AN-GTM-16-215

3

@

F4B-GTMAH-300

129939

AN-GTM-16-300

75mm

@

F4B-GTMAH-75M

129965

AN-GTM-16-75M

218

3-7/16

129704

F4B-GTMAH-307

129489

F4B-GTAH-18

129940

AN-GTM-18-307

3-1/2

@

F4B-GTMAH-308

129941

AN-GTM-18-308

85mm

@

F4B-GTMAH-85M

129966

AN-GTM-18-85M

Series

Shaft Size

Weight lbs. kg

A

B

C#

D

F Bolt Dia.

H

J

L

N

Z

211

1-15/16

11.1

1-59/64

6-1/2

2-9/64

5-1/8

5/8

11/16

11/16

3-1/4

3-1/4

2-9/32

2

11.0

50mm

5.4

48.8

165.1

54.4

130.2

M16

17.5

17.5

82.6

82.6

57.9

212

2-3/16

13.4

2-7/64

6-7/8

2-5/16

5-5/8

5/8

11/16

23/32

3-1/2

3-1/2

2-7/16

2-1/4

13.3

55mm

6.5

53.6

174.6

58.7

142.9

M16

17.5

18.3

88.9

88.9

61.9

214

2-7/16

14.7

2-25/64

7-3/8

2-53/64

5-7/8

5/8

11/16

23/32

3-13/16

3-11/16

2-29/32

2-1/2

14.6

65mm

7.1

60.7

187.3

71.8

149.2

M16

17.5

18.3

96.8

93.7

73.8

215

2-11/16 70mm

19.0 9.2

2-29/64 62.3

7-3/4 196.9

3-3/16 81.0

6 152.4

3/4 M18

1 25.4

51/64 20.2

4-1/4 108.0

3-7/8 98.4

3-3/64 77.4

216

2-15/16

20.7

2-11/16

7-3/4

3-3/8

6

3/4

7/8

57/64

4-1/2

4-9/32

3-25/64

3

20.6

75mm

10.0

68.3

196.9

85.7

152.4

M18

22.2

22.6

108.7

104.0

86.1

218

3-7/16 85mm

36.1 17.5

2-51/64 71.0

8-7/16 214.3

3-37/64 90.9

6-3/4 171.5

3/4 M18

1 25.4

53/64 21.0

5 127.0

4-5/8 117.5

3-39/64 91.7
