Series

Shaft Size

Complete Unit Part No.              Description

Unit without Adapter Sleeve & Lock Nut Part No.                  Description

Adapter Sleeve & Lock Nut Assembly Part No.                  Description

205

3/4

@

F4B-GTMAH-012

129476

F4B-GTAH-05

129924

AN-GTM-05-012

206

1 25mm

129697 @

F4B-GTMAH-100 F4B-GTMAH-25M

129477

F4B-GTAH-06

129925 129957

AN-GTM-06-100 AN-GTM-06-25M

207

1-3/16

129698

F4B-GTMAH-103

129478

F4B-GTAH-07

129926

AN-GTM-07-103

1-1/4

@

F4B-GTAH-104

129911

AN-GT-07-104

30mm

@

F4B-GTMAH-30M

129954

AN-GTM-07-30M

208

1-7/16 35mm

129699 @

F4B-GTMAH-107 F4B-GTMAH-35M

129479

F4B-GTAH-08

129927 129958

AN-GTM-08-107 AN-GTM-08-35M

209

1-1/2 40mm

@ @

F4B-GTMAH-108 F4B-GTMAH-40M

129480

F4B-GTAH-09

129928 129959

AN-GTM-09-108 AN-GTM-09-40M

210

1-11/16

064670

F4B-GTMAH-111

129481

F4B-GTAH-10

129929

AN-GTM-10-111

1-3/4

@

F4B-GTMAH-112

129930

AN-GTM-10-112

45mm

@

F4B-GTMAH-45M

129960

AN-GTM-10-45M

Series

Shaft Size

Weight lbs. kg

A

B

C#

D

F Bolt Dia.

H

J

L

N

Z

205

3/4

2.3

1-29/64

3-3/4

1-35/64

2-3/4

7/16

1/2

21/32

1-51/64

2-1/16

1-35/64

206

1 25mm

3.9 1.9

1-39/64 40.9

4-1/4 108.0

1-45/64 43.3

3-1/4 82.6

7/16 M10

1/2 12.7

11/16 17.5

2-5/64 52.8

2-3/16 55.6

1-3/4 44.5

207

1-3/16

4.5

1-5/8

4-3/4

1-49/64

3-5/8

1/2

9/16

41/64

2-3/8

2-7/16

1-55/64

1-1/4

4.4

30mm

2.2

41.3

120.7

44.8

92.1

M12

14.3

16.3

60.3

61.9

47.2

208

1-7/16 35mm

5.9 2.9

1-27/32 46.8

5-1/8 130.2

1-31/32 50.0

4 101.6

1/2 M12

9/16 14.3

43/64 17.1

2-5/8 66.7

2-3/8 60.3

2-7/32 56.4

209

1-1/2 40mm

6.1 3.0

1-55/64 47.2

5-3/8 136.5

2 50.8

4-1/8 104.8

1/2 M12

5/8 15.9

11/16 17.5

2-55/64 72.6

2-3/4 69.9

2-3/32 53.2

210

1-11/16

7.1

1-55/64

5-5/8

2-3/64

4-3/8

1/2

5/8

21/32

3-1/8

2-7/8

2-1/8

1-3/4

7.0

45mm

3.4

47.2

142.9

52.0

111.1

M12

15.9

16.7

79.4

73.0

54.0
