FB-GT-015、FB-GT-104

Series

Shaft Size

Complete Unit Part No.              Description

Unit without Adapter Sleeve & Lock Nut Part No.           Description

Adapter Sleeve & Lock Nut Assembly Part No.   Description

204

3/4

129615

FB-GT-012

129511

FB-GT-04

129904

AN-GT-04-012

205

7/8

129616

FB-GT-014

129512

FB-GT-05

129905

AN-GT-05-014

15/16

129617

FB-GT-015

129906

AN-GT-05-015

1

129618

FB-GT-100

129907

AN-GT-05-100

206

1-1/8

129619

FB-GT-102

129513

FB-GT-06

129908

AN-GT-06-102

1-3/16

129620

FB-GT-103

129909

AN-GT-06-103

1-1/4

129621

FB-GT-104S

129910

AN-GT-06-104S

207

1-1/4

129622

FB-GT-104

129514

FB-GT-07

129911

AN-GT-07-104

1-3/8

129623

FB-GT-106

129912

AN-GT-07-106

1-7/16

129624

FB-GT-107

129913

AN-GT-07-107

210

1-15/16 2

129625 129626

FB-GT-115 FB-GT-200

129515

FB-GT-10

129918 129919

AN-GT-10-115 AN-GT-10-200

Shaft Size

Weight lbs

F

Series

A

B

C#

D

E

Bolt

G

H

I

J

K

L

M

Z

Dia.

204

3/4

1.3

1-15/32

4-1/4

1-19/32

1-1/2

1-11/16

3/8

7/8

5/16

3

2-1/2

63/64

1-1/2

2-3/8

1-21/2

205

7/8 15/16 1

2.3

1-29/64

4-3/4

1-11/16

1-5/8

1-13/16

3/8

1-1/8

3/8

3-3/8

2-3/4

1-7/64

1-51/64

2-1/2

1-3/4

206

1-1/8

3.2

1-39/64

5-3/8

1-25/32

1-7/8

2-1/16

3/8

1-1/4

3/8

3-3/4

3-1/4

1-1/8

2-5/64

2-3/4

1-53/64

1-3/16

3.2

1-1/4

3.1

207

1-1/4

3.4

1-5/8

6-1/8

1-57/64

2

2-3/8

1/2

1-1/4

1/2

4-1/4

3-3/4

1-5/16

2-3/8

3-1/4

1-31/32

1-3/8

3.4

1-7/16

3.4

210

1-15/16 2

5.7 5.6

1-55/64

7-1/2

2-5/64

2-3/4

2-15/16

1/2

1-5/8

1/2

5-3/16

4-5/8

1-1/2

3-1/8

4

2-5/32
