F2B-GTAH-110、F2B-GTAH-45M

Series

Shaft Size

Complete Unit Part No.             Description

Unit without Adapter Sleeve & Lock Nut Part  No.                 Description

Adapter Sleeve & Lock Nut Part No.             Description

208

1-1/2

@

F2B-GTAH-108

@

F2B-GTAH-08

129914

AN-GT-08-108

1-5/8

@

F2B-GTAH-110

129955

AN-GT-08-110

40mm

@

F2B-GTAH-40M

129947

AN-GT-08-40M

209

1-5/8

@

F2B-GTAH-110L

@

F2B-GTAH-09

129915

AN-GT-09-110L

1-11/16

@

F2B-GTAH-111

129916

AN-GT-09-111

1-3/4

@

F2B-GTAH-112

129917

AN-GT-09-112

45mm

@

F2B-GTAH-45M

129948

AN-GT-09-45M

210

1-15/16

@

F2B-GTAH-115

@

F2B-GTAH-10

129918

AN-GT-10-115

2

@

F2B-GTAH-200

129919

AN-GT-10-200

50mm

@

F2B-GTAH-50M

129949

AN-GT-10-50M

211

2

@

F2B-GTMAH-200

@

F2B-GTAH-11

129932

AN-GTM-11-200

2-3/16

@

F2B-GTAH-203

129920

AN-GT-11-203

2-1/4

@

F2B-GTAH-204

129956

AN-GT-11-204

55mm

@

F2B-GTAH-55M

129950

AN-GT-11-55M

212

2-1/4

@

F2B-GTMAH-204

@

F2B-GTAH-12

129934

AN-GTM-12-204

2-7/16

@

F2B-GTAH-207

129921

AN-GT-12-207

60mm

@

F2B-GTAH-60M

129951

AN-GT-12-60M

Series

Shaft Size

Weight Lbs kg

A

B

C#

D

F Bolt Dia.

H

J

L

M

N

Z

208

1-1/2

5.0

1-27/32

6-3/4

1-31/32

5-21/32

1/2

9/16

43/64

2-5/8

4-1/8

1-53/64

2-7/32

1-5/8

4.8

40mm

2.3

46.8

171.5

50.0

143.7

M12

14.3

17.1

66.7

104.8

46.4

56.4

209

1-5/8

6.2

1-55/64

7-1/16

2

5-27/32

1/2

5/8

11/16

2-55/64

4-3/8

1-29/32

2-3/32

1-11/16 1-3/4

6.1 6.0

45mm

2.7

47.2

179.4

50.8

148.4

M12

15.9

17.5

72.6

111.1

48.4

53.2

210

1-15/16

6.9

1-55/64

7-7/16

2-3/64

6-3/16

1/2

5/8

21/32

3-1/8

4-9/16

2-1/32

2-1/8

2

6.8

50mm

3.2

47.2

188.9

52.0

157.2

M12

15.9

16.7

79.4

115.9

51.6

54.0

211

2

8.0

1-59/64

8-5/8

2-5/32

7-1/4

5/8

11/16

11/16

3-27/64

5-1/4

2-17/64

2-9/32

2-3/16 2-1/4

7.9 7.8

55mm

3.7

48.8

219.1

54.8

184.2

M16

17.5

17.5

86.9

133.4

57.5

57.9

212

2-1/4

9.3

2-7/64

9-13/16

2-5/16

7-61/64

7/8

13/16

23/32

3-11/16

5-1/2

2-15/32

2-7/16

2-7/16

9.2

60mm

4.5

53.6

249.2

58.7

202.0

M22

20.6

18.3

93.7

139.7

62.7

61.9
