WSTU-GTEZ-103-PCR、WSTU-GTEZ-20M-PCR

Series

Shaft Size

With Corrosion

 Resistant Insert Part No.

Description

Unit without Adapter

 & Nut Part No.     Description

Adapter & Nut

Assembly Part No.  Description

204

3/4

20 mm

136315

136323

WSTU-GTEZ-012-PCR

WSTU-GTEZ-20M-PCR

136327

WSTU-GTEZ-04-PCR

129967

129980

AN-GT-04-012-CR

AN-GT-04-20M-CR

205

1

25 mm

136316

136324

WSTU-GTEZ-100-PCR

WSTU-GTEZ-25M-PCR

136328

WSTU-GTEZ-05-PCR

129968

129981

AN-GT-05-100-CR

AN-GT-05-25M-CR

206

1-1/8

136317

WSTU-GTEZ-102-PCR

136329

WSTU-GTEZ-06-PCR

129969

AN-GT-06-102-CR

1-3/16

136318

WSTU-GTEZ-103-PCR

129970

AN-GT-06-103-CR

1-1/4

136319

WSTU-GTEZ-104S-PCR

129971

AN-GT-06-104S-CR

30 mm

136325

WSTU-GTEZ-30M-PCR

129982

AN-GT-06-30M-CR

207

1-1/4

136320

WSTU-GTEZ-104-PCR

136330

WSTU-GTEZ-07-PCR

129972

AN-GT-07-104-CR

1-3/8

136321

WSTU-GTEZ-106-PCR

129973

AN-GT-07-106-CR

1-7/16

136322

WSTU-GTEZ-107-PCR

129974

AN-GT-07-107-CR

35 mm

136326

WSTU-GTEZ-35M-PCR

129983

AN-GT-07-35M-CR

Series

Shaft Size

Weight

lbs

kg

Take-Up

Frame No. Ref.

A

B

C**

D

E

F

Thd

G

204

3/4

20 mm

0.90

0.40

WS300

1-15/32

37.3

3-13/16

96.8

17/32

13.5

2

50.8

2-1/2

63.5

5/8

15.9

1/2

12.7

205

1

25 mm

1.20

0.50

WS300

1-29/64

36.9

3-15/16

100.1

17/32

13.5

2

50.8

2-9/16

65.0

5/8

15.9

1/2

12.7

206

1-1/8

1.80

WS308

1-39/64

4-1/2

17/32

2-1/4

2-7/8

3/4

1/2

1-3/16

1-1/4

1.70

1.60

30 mm

0.80

40.9

114.3

13.5

57.2

73.0

19.1

12.7

207

1-1/4

2.40

WS308

1-5/8

4-15/16

17/32

2-1/4

3-1/8

3/4

1/2

1-3/8

1-7/16

2.30

2.30

35 mm

1.08

41.3

125.2

13.5

57.2

79.2

19.1

12.7
