Rod End No.

DIMENSIONS IN INCHES

a°

Misalgn.

Angle

Ultimate Radial

Static Load

Capacity Lbs.

Approx.

Brg. Wt.

 Lbs.

Right

Hand

Left

Hand†

B

+ .0015

- .0005

W

+ .000

- .005

H

+.005

A

+.015

D

+.010

K

+.010

J

+.010

Ball

Dia. Ref.

C

+ .062

- .031

Thread

UNF-2B

MW-3T

MG-3T

.1900

.312

.250

1.062

.625

.406

.312

.437

.562

10-32

13

1,531

.038

MW-4T

MG-4T

.2500

.375

.281

1.312

.750

.469

.375

.500

.750

1/4-28

16

2,539

.059

MW-5T

MG-5T

.3125

.437

.344

1.375

.875

.500

.437

.625

.750

5/16-24

14

3,133

.092

MW-6T

MG-6T

.3750

.500

.406

1.625

1.000

.687

.562

.719

.937

3/8-24

12

3,915

.152

MW-7T

MG-7T

.4375

.562

.437

1.812

1.125

.750

.625

.812

1.062

7/16-20

14

4,218

.198

MW-8T

MG-8T

.5000

.625

.500

2.125

1.312

.875

.750

.937

1.187

1/2-20

12

6,660

.329

MW-10T

MG-10T

.6250

.750

.562

2.500

1.500

1.000

.875

1.125

1.500

5/8-18

16

7,364

.477

MW-12T

MG-12T

.7500

.875

.687

2.875

1.750

1.125

1.000

1.312

1.750

3/4-16

14

11,518

.723

MW-14T

MG-14T

.8750

.875

.765

3.375

2.000

1.300

1.125

1.375

1.875

7/8-14

7

18,476

1.030

MW-16T

MG-16T

1.0000

1.375

1.000

4.125

2.750

1.625

1.500

1.875

2.125

1 1/4-12

17

40,889

2.125

MW-16T-1

MG-16T-1

1.0000

1.375

1.000

4.125

2.750

1.625

1.500

1.875

2.125

1-143

17

43,541

2.410

MW-16T-2

MG-16T-2

1.0000

1.375

1.000

4.125

2.750

1.625

1.500

1.875

2.125

1-12

17

43,541

2.410
