ROD END NO.

DIMENSIONS IN INCHES

a° Misalign.

 Angle

Ultimate Radial

Static Load

Capacity Lbs.

Approx.

Brg. Wt.

Lbs.

Right

Hand

Left

Hand†

B

+ .0025

-.0005

W

± .005

H

Ref.

A

± .015

D

Ref.

K

± .010

J

± .010

Ball Dia.

Ref.

C

+ .062

- .031

Thread

UNF-2B

VCW-5

VCG-5

.3125

.437

.312

1.375

.875

.500

.437

.593

.687

5/16-24

18

2,623

.08

VCW-6

VCG-6

.3750

.500

.359

1.625

1.000

.687

.562

.687

.812

3/8-24

18

3,643

.13

VCW-7

VCG-7

.4375

.562

.406

1.812

1.125

.750

.625

.781

.937

7/16-20

17

4,464

.18

VCW-8

VCG-8

.5000

.625

.453

2.125

1.312

.875

.750

.875

1.062

1/2-20

16

7,229

.29

VCW-10

VCG-10

.6250

.750

.484

2.500

1.500

1.000

.875

1.062

1.375

5/8-18

22

8,204

.43

VCW-12

VCG-12

.7500

.875

.593

2.875

1.750

1.125

1.000

1.250

1.562

3/4-16

20

12,280

.65
