1666-193-10、1666-893-10、1666-293-10

Size

Accuracy class

Part numbers for runner blocks for preload class

up to approx. 10m clearance

Preload

0.02 C

15

H

1666-193-10

1666-113-10

N

1666-194-10

1666-114-10

20

H

1666-893-10

1666-813-10

N

1666-894-10

1666-814-10

25

H

1666-293-10

1666-213-10

N

1666-294-10

1666-214-10

30

H

1666-793-10

1666-713-10

N

1666-794-10

1666-714-10

35

H

1666-393-10

1666-313-10

N

1666-394-10

1666-314-10

Dimensions (mm)

Size

A

A1

A2

A3

B

B1

H

H1

H21)

H22)

V1

E1

E8

E9

N3

15

34

17

15

9.5

40.5

25.7

24

19.8

16.3

16.20

5.0

26

24.55

6.7

6.0

20

44

22

20

12.0

52.5

31.9

30

25.4

20.7

20.55

6.0

32

32.4

7.3

7.5

25

48

24

23

12.5

61.5

38.6

36

29.5

24.4

24.25

7.5

35

38.3

11.5

9.0

30

60

30

28

16.0

71.5

45.0

42

35.0

28.5

28.35

7.0

40

48.4

14.6

12.0

35

70

35

34

18.0

79.0

51.4

48

40.0

32.15

31.85

8.0

50

58.0

17.5

13.0
