TA323、TA335、TA347

Shaft Diameter

Part Number

H

Adjusting

Screw Hole Diameter

N

Slot Spacing

S

Slot Width

A

C

D

F

G

J

K

L

M

T

U

Y

Approx. Weight

1 7/16

TA323

7/8

3.500

0.531

4

2 3/4

2 47/64

2 3/8

1 7/16

5 1/4

1 5/8

4 1/8

2 3/8

5/8

1 29/32

3 1/4

5.00 lb

1 15/16

TA331

1 1/4

5.125

0.812

5 1/2

4

3 7/32

3 3/4

2 1/4

7 3/8

2 3/16

5 7/8

2 55/64

1

2 1/8

4 5/8

13.50 lb

2 3/16

TA335

1 1/4

5.500

0.812

5 13/16

4 1/8

3 23/64

3 3/4

2 1/4

7 3/4

2 3/8

6 1/4

3 15/64

1

2 9/64

4 27/32

16.00 lb

2 7/16

TA339

1 3/8

6.000

1.062

6 1/4

4 1/2

3 27/32

4 1/8

2 1/2

8 5/8

2 9/16

6 3/4

3 19/32

1 3/8

2 25/64

5 7/16

20.00 lb

2 15/16

TA347

1 5/8

7.500

1.312

8

5 3/4

4 17/32

4 3/4

2 3/4

10 1/2

3 1/4

8 1/4

4 3/32

1 1/4

2 51/64

6 1/2

38.00 lb
