PLB23252K9716、PLB23264K111516、PLB23280K15

Shaft   Diameter

Part Number

A Base to  Centerline  Height

B Min.  Distance  Between  Bolt Holes

B Max.  Distance  Between  Bolt Holes

G Bolt Hole  Spacing (Width)

C

E

F Bolts

H

K

L

Approx. Weight

8

PLB23244K8

9 1/2

24 3/4

27 7/8

5 1/4

32 3/4

8 3/4

1 1/2

3 3/4

13 1/8

18 5/8

712.00

8 15/16

PLB23248K81516

10 1/4

29

30 1/2

8 3/4

35

14 1/2

1 5/8

3 3/4

14 1/8

20 1/2

1,080.00

9 7/16

PLB23252K9716

12

32 3/4

33 1/2

9

38 1/4

15 1/8

1 5/8

3 1/2

16 1/2

24

1,301.00

10 7/16

PLB23256K10716

12

32 3/4

33 1/2

9

38 1/4

15 1/8

1 5/8

3 1/2

16 1/2

24

1,400.00

10 15/16

PLB23260K101516

12 13/16

35

36 1/2

10 1/2

41 3/4

15 3/4

1 7/8

4 1/2

16 1/4

26

1,822.00

11 15/16

PLB23264K111516

14

36 3/4

38 1/4

10 3/4

43 3/4

18 1/4

2

5

18

28

2,173.00

12 7/16

PLB23268K12716

14 1/2

39 1/4

40 3/4

11

46

17 1/8

2

5

18

28 3/4

2,582.00

13 7/16

PLB23272K13716

15 1/2

41 1/2

43 1/2

12 1/4

48 3/4

18 3/4

2 1/4

5 1/2

19 3/8

31

3,278.00

13 15/16

PLB23276K131516

15 1/2

41 1/2

43 1/2

12 1/4

48 3/4

18 3/4

2 1/4

5 1/2

19 3/8

31

3,245.00

15

PLB23280K15

17

44 1/2

46 5/8

14 1/2

52 3/4

22 1/4

2 1/4

5 1/2

21 3/4

34

4,297.00

15 3/4

PLB23284K1534

18

47 1/8

48 7/8

15

54 1/4

21 5/8

2 1/2

5 3/4

22 3/4

35 3/4

4,800.00

16 1/2

PLB23288K1612

18

47 1/8

48 7/8

15

54 1/4

21 5/8

2 1/2

5 3/4

22 3/4

35 3/4

4,798.00

17

PLB23292K17

18

47 1/8

48 7/8

15

54 1/4

21 5/8

2 1/2

5 3/4

22 3/4

35 3/4

4,461.00

18

PLB23296K18

20

52 1/2

54

16

60

22

3

6

24 5/8

40

6,362.00
