四螺栓法兰SF-204TMC、SF-205TMC、SF-206TMC、SF-207TMC

SF-T 系列标准四螺栓法兰 － SKWEZLOC 锁环 － 公制 － SKWEZTM

孔径

型号

轴承芯件

-编号

基本动态

额定载荷

牛/磅

尺寸，毫米/英寸

螺栓

-尺寸

单元

重量

公斤/磅

A

B*

D

G

H

J

L

M

N

T-芯

毫米

20

SF-204TMC

5204TMC

11614

2611

85.7

3-3/8

63.5

2-1/2

23.4

59/64

11.1

7/16

34.1

1-11/32

32.5

1-9/32

44.5

1-3/4

59.5

2-11/32

12.7

1/2

50.8

2

M10

.73

1.6

25

SF-205TMC

5205TMC

12459

2801

95.3

3-3/4

69.9

2-3/4

26.2

1-1/32

13.5

17/32

38.1

1-1/2

36.5

1-7/16

49.2

1-15/16

69.1

2-23/32

14.3

9/16

60.3

2-3/8

M10

1.04

2.3

30

SF-206TMC

5206TMC

19487

4381

108.0

4-1/4

82.6

3-1/4

29.8

1-11/64

13.5

17/32

41.3

1-5/8

39.7

1-9/16

55.6

2-3/16

81.8

3-7/32

15.9

5/8

73.0

2-7/8

M12

1.72

3.8

35

SF-207TMC

5207TMC

25718

5782

117.5

4-5/8

92.1

3-5/8

34.1

1-11/32

14.3

9/16

46.0

1-13/16

44.5

1-3/4

65.1

2-9/16

94.5

3-23/32

17.5

11/16

88.9

3-1/2

M14

2.00

4.4

40

SF-208TMC

5208TMC

32648

7340

130.2

5-1/8

101.6

4

38.1

1-1/2

14.3

9/16

52.8

2-5/64

50.8

2

68.3

2-11/16

104.8

4-1/8

19.1

3/4

98.4

3-7/8

M14

2.63

5.8

45

SF-209TMC

5209TMC

35144

7901

136.5

5-3/8

104.8

4-1/8

39.7

1-9/16

14.3

9/16

53.6

2-7/64

50.8

2

74.6

2-15/16

109.9

4-21/64

19.1

3/4

98.4

3-7/8

M14

2.72

6.0

50

SF-210TMC

5210TMC

35090

7889

142.9

5-5/8

111.1

4-3/8

39.7

1-9/16

14.3

9/16

56.4

2-7/32

53.2

2-3/32

85.7

3-3/8

114.7

4-33/64

19.1

3/4

101.6

4

M16

3.18

7.0

55

SF-211TMC

5211TMC

43377

9752

161.9

6-3/8

130.2

5-1/8

44.5

1-3/4

20.6

13/16

60.3

2-3/8

57.2

2-1/4

92.1

3-5/8

131.8

5-3/16

22.2

7/8

108.0

4-1/4

M16

5.03

11.1

60

SF-212TMC

5212TMC

52437

11789

174.6

6-7/8

142.9

5-5/8

49.2

1-15/16

20.6

13/16

69.9

2-3/4

104.8

4-1/8

104.8

4-1/8

138.1

5-7/16

25.4

1

127.0

5

M16

5.90

13.0
