采用双锁紧 － 固定螺钉锁紧的 MFPD 系列中载荷四螺栓底座立式座

孔径

型号

轴承芯

件-编号

基本动态-

额定载荷

-磅/牛

尺寸（英寸/毫米）

螺栓

-尺寸

单元-

重量-

磅/公斤

A

B

C

D

E

G

H

J

K

L

英寸

最小

最大

1-15/16

MFPD-31

3-115D

9752

43377

2-1/2

63.5

9-3/4

247.7

6-3/8

161.9

7-5/8

193.7

4

101.6

2-1/4

57.2

13/16

20.6

5-3/8

136.5

2-5/8

66.7

1-5/16

33.3

2-23/32

69.1

5/8

13.7

6.21

2-3/16

MFPD-35

3-23D

11789

52437

2-3/4

69.9

10-1/4

260.4

6-7/8

174.6

8-1/8

206.4

4-1/8

104.8

2-1/4

57.2

7/8

22.2

5-13/16

147.6

3-1/8

79.4

1-9/16

39.7

2-63/64

75.8

5/8

17

7.71

2-7/16

2-1/2

MFPD-39

MFPD-40

3-27D

3-28D

13971

62143

3

76.2

11-1/4

285.8

7-1/2

190.5

9

228.6

4-1/2

114.3

2-5/8

66.7

1

25.4

6-1/2

165.1

3-1/2

88.9

1-3/4

44.5

3-7/16

87.3

5/8

23.3

10.57

2-11/16

MFPD-43

3-211D

14839

66004

3-1/2

88.9

13

330.2

9

228.6

10-1/2

266.7

5

127.0

2-3/4

69.9

1-1/8

28.6

7-1/4

184.2

3-1/2

88.9

1-3/4

44.5

3-41/64

92.5

3/4

34

863.6

2-15/16

3

MFPD-47

MFPD-48

3-215D

3-3D

17412

77449

3-1/2

88.9

13

330.2

9

228.6

10-1/2

266.7

5

127.0

2-3/4

69.9

1

25.4

7-3/8

187.3

3-7/8

98.4

1-15/16

49.2

3-59/64

99.6

3/4

36.5

16.56

3-7/16

3-1/2

MFPD-55

MFPD-56

3-37D

2-38D

21566

95926

4

101.6

15

381.0

25-3/4

654.1

12-1/4

311.2

5

127.0

3

76.2

1-1/16

27.0

8-7/16

214.3

4-39/89

112.7

2-7/32

56.4

4-25/64

111.5

3/4

48.6

22.04

3-15/16

4

MFPD-63

MFPD-64

3-315D

3-4D

29905

133017

5

127.0

17

431.8

12-7/16

315.9

14-1/16

357.2

6

152.4

3-1/2

88.9

1-1/4

31.8

10-1/4

260.4

5-3/8

136.5

2-11/16

68.3

5-11/64

131.4

7/8

83.5

37.87

4-7/16

4-15/16

5

MFPD-71

MFPD-79*

MFPD-80

3-47D

3-415D

3-500D

37482

166720

6

152.4

19

482.6

14

355.6

16

406.4

5-1/2

139.7

3-1/4

82.6

1-5/8

41.3

12-1/8

308.0

5-3/4

146.1

2-7/8

73.0

6-11/32

161.1

1

130.0

58.97
