型號

B

W

O

H

D

F

A

J

K

L

A/F

Thread

旋角

球徑
Ball Dia.
Ø

徑向荷重
Radial S. load
(kgf)

重量
Weight

 (g)

Model No.

H7

+0 -0.1

＊

+0-0.1

＊

＊

+2 -0

＊

＊

＊

+0-0.3

S

α

PHS 5 R/L

5

8

7.7

6

17

27

12

9

11

4

9

5x0.8

13

11.11

560

18

PHS 6 R/L

6

9

8.9

6.7

19

30

14

10

13

5

11

6x1.0

13

12.70

690

27

PHS 8 RF/LF
PHS 8 R/L

8

12

10.4

9

23.5

36

17

13

16

5

14

8x1.0
8x1.25

13

15.88

980

48

PHS 10 RF/LF
PHS 10 R/L

10

14

12.9

10.5

27

45

21

15

19

7

17

10x1.25
10x1.5

13

19.05

1,320

82

PHS 12 RF/LF
PHS 12 R/L

12

16

15.4

12

32

50

24

18

22

7

19

12x1.25
12x1.75

13

22.23

1,670

123

PHS 14 RF/LF
PHS 14 R/L

14

19

16.8

14

36

57

27

20

25

8

21

14x1.5
14x2.0

15

25.40

2,060

170

PHS 16 RF/LF
PHS 16 R/L

16

21

19.3

15

39

64

33

22

27

8

22

16x1.5
16x2.0

15

28.58

2,500

214

PHS 18 R/L

18

23

21.8

17

44

71

36

25

31

10

27

18x1.5

15

31.75

2,940

305

PHS 20 R/L

20

25

24.3

18

47

77

40

28

34

10

30

20x1.5

15

34.93

3,430

387

PHS 22 R/L

22

28

25.9

20

50

84

43

30

37

12

32

22x1.5

15

38.10

4,120

540

PHS 25 R/L

25

31

29.6

22

56

94

48

34

42

12

36

24x2.0

15

42.85

7,240

750

PHS 30 R/L

30

37

34.8

26

67

110

56

40

50

15

41

30x2.0

15

50.80

9,210

1,130
