BEARING
PART
NUMBER
1) |
Fw
Inside Diameter |
D
Outside Diameter |
B
Width
+.000
–.005 |
r1
Housing
Fillet
Max. |
Housing
Shoulder
Dia.
+/– 1/64" |
Dynamic
Capacity
C (lbs.) |
Static
Capacity
CO(lbs.) |
Nominal |
Min. |
Max. |
Max. |
Min. |
TJ 75317 |
1.4995 |
1.063 |
7/8 |
.8759 |
1.5000 |
.8768 |
.015 |
1 1/4 |
10,800 |
7,300 |
TJ 7194 |
1.4995 |
1.000 |
1 |
1.0009 |
1.5000 |
1.0018 |
.015 |
1 5/16 |
13,700 |
8,000 |
TJ 74765 |
1.6870 |
1.000 |
1 1/16 |
1.0640 |
1.6875 |
1.0649 |
.015 |
1 7/16 |
13,900 |
9,500 |
TJ 7214 |
1.6245 |
1.000 |
1 1/8 |
1.1259 |
1.6250 |
1.1268 |
.040 |
1 3/8 |
15,500 |
8,500 |
TJ 7215 |
1.6245 |
1.250 |
1 1/8 |
1.1259 |
1.6250 |
1.1268 |
.040 |
1 3/8 |
20,400 |
10,600 |
TJ 7235 |
1.7495 |
1.250 |
1 1/4 |
1.2510 |
1.7500 |
1.2519 |
.040 |
1 9/16 |
22,700 |
11,300 |
TJ 75117 |
2.0619 |
1.000 |
1 3/8 |
1.3760 |
2.0625 |
1.3769 |
.015 |
1 3/4 |
17,900 |
10,100 |
TJ 75129 |
2.2494 |
1.000 |
1 1/2 |
1.5010 |
2.2500 |
1.5019 |
.015 |
1 7/8 |
18,900 |
11,300 |
TJ 75318 |
2.3744 |
1.250 |
1 1/2 |
1.5010 |
2.3750 |
1.5019 |
.060 |
2 |
24,400 |
15,000 |
DTJ 75319 |
2.3744 |
2.500 |
1 1/2 |
1.5010 |
2.3750 |
1.5019 |
.060 |
2 |
48,900 |
25,800 |
TJ 7314 |
2.3119 |
1.000 |
1 3/4 |
1.7510 |
2.3125 |
1.7520 |
.060 |
2 1/16 |
23,900 |
11,500 |
TJ7315 |
2.3119 |
1.250 |
1 3/4 |
1.7510 |
2.3125 |
1.7520 |
.060 |
2 1/16 |
31,800 |
14,300 |
TJ7354 |
2.5619 |
1.000 |
2 |
2.0011 |
2.5625 |
2.0021 |
.060 |
2 5/16 |
27,700 |
12,500 |
TJ 7355 |
2.5619 |
1.250 |
2 |
2.0011 |
2.5625 |
2.0021 |
.060 |
2 5/16 |
36,800 |
15,600 |
TJ 8446 |
3.2494 |
1.500 |
2 1/2 |
2.5011 |
3.2500 |
2.5021 |
.080 |
2 7/8 |
46,600 |
19,000 |
TJ 8447 |
3.2494 |
1.750 |
2 1/2 |
2.5011 |
3.2500 |
2.5021 |
.080 |
2 7/8 |
56,900 |
22,200 |
TJ 8476 |
3.4992 |
1.500 |
2 3/4 |
2.7511 |
3.5000 |
2.7521 |
.080 |
3 1/8 |
49,800 |
19,500 |
TJ 8477 |
3.4992 |
1.750 |
2 3/4 |
2.7511 |
3.5000 |
2.7521 |
.080 |
3 1/8 |
60,900 |
22,800 |
TJ 8516 |
3.7492 |
1.500 |
3 |
3.0011 |
3.7500 |
3.0023 |
.080 |
3 3/8 |
56,000 |
20,900 |
TJ 8517 |
3.7492 |
1.750 |
3 |
3.0011 |
3.7500 |
3.0023 |
.080 |
3 3/8 |
68,500 |
24,400 |
DTJ 75168 |
4.2492 |
4.000 |
3 1/4 |
3.2512 |
4.2500 |
3.2524 |
.060 |
3 3/4 |
164,500 |
54,500 |
TJ 75310 |
3.9992 |
1.500 |
3 5/16 |
3.3151 |
4.0000 |
3.3160 |
.060 |
3 5/8 |
64,400 |
20,900 |
TJ 75309 |
3.9992 |
1.650 |
3 5/16 |
3.3151 |
4.0000 |
3.3160 |
.060 |
3 5/8 |
72,600 |
22,900 |
TJ 9608 |
4.4992 |
2.000 |
3 1/2 |
3.5012 |
4.5000 |
3.5014 |
.060 |
3 7/8 |
87,900 |
32,800 |
TJ 75177 |
4.3742 |
1.500 |
3 13/16 |
3.8143 |
4.3750 |
3.8157 |
.060 |
4 |
76,000 |
18,400 |
TJ 75311 |
4.8118 |
2.125 |
4 |
4.0012 |
4.8125 |
4.0024 |
.060 |
4 3/8 |
116,000 |
34,100 |
TJ 75176 |
4.6242 |
1.500 |
4 1/16 |
4.0643 |
4.6250 |
4.0657 |
.060 |
4 5/16 |
81,000 |
18,900 |
TJ 75312 |
5.3118 |
2.080 |
4 1/2 |
4.5012 |
5.3125 |
4.5026 |
.060 |
4 7/8 |
127,000 |
36,200 |
TJ 6769 |
5.9990 |
2.250 |
4 1/2 |
4.5012 |
6.0000 |
4.5026 |
.100 |
5 1/4 |
119,000 |
49,600 |
TJ 6770 |
5.9990 |
2.500 |
4 1/2 |
4.5012 |
6.0000 |
4.5026 |
.100 |
5 1/4 |
137,000 |
55,400 |
DTJ 75169 |
5.9990 |
4.500 |
4 1/2 |
4.5012 |
6.0000 |
4.5026 |
.100 |
5 1/4 |
236,000 |
85,800 |
TJ 74986 |
5.9990 |
2.000 |
5 |
5.0013 |
6.0000 |
5.0027 |
.100 |
5 1/2 |
135,000 |
39,000 |
TJ 6849 |
6.4990 |
2.250 |
5 |
5.0013 |
6.5000 |
5.0027 |
.100 |
5 3/4 |
137,000 |
54,000 |
TJ 6918 |
6.9990 |
2.500 |
5 1/2 |
5.5013 |
7.0000 |
5.5027 |
.100 |
6 1/4 |
169,000 |
62,000 |
TJ 6919 |
6.9990 |
3.000 |
5 1/2 |
5.5013 |
7.0000 |
5.5027 |
.100 |
6 1/4 |
213,000 |
74,200 |
DTJ 75170 |
6.9990 |
6.000 |
5 1/2 |
5.5013 |
7.0000 |
5.5027 |
.100 |
6 1/4 |
425,000 |
127,000 |
TJ 6926 |
7.4988 |
3.000 |
6 |
6.0013 |
7.5000 |
6.5029 |
.120 |
6 5/8 |
239,000 |
79,300 |
TJ 6935 |
7.9988 |
2.500 |
6 1/2 |
6.5013 |
8.0000 |
6.5029 |
.120 |
7 1/8 |
200,000 |
67,500 |
DTJ 75166 |
10.1236 |
7.750 |
8 |
8.0014 |
10.1250 |
8.0032 |
.160 |
9 1/4 |
830,000 |
260,000 | |
