B-88轴承尺寸规格 |
尺寸BEARING DIMENSIONS MECHANICALLY RETAINED ROLLERS BEARING MOUNTING
Load Ratings Inch Mounting
Fw D C Basic Basic Working Limiting X S H
Bore Outside Width Bearing Dynamic Static Load Speed End Shaft Housing Bore
Diameter Designation Cr Co Full Thickness Raceway
Comple- Diameter
+0.000 +0,00 open closed ISO ISO ment
(nom.) (nom.) -0.010 -0,25 end end T 281 76 (max.) Bearings (max.) inches inches
inch mm inch mm inch mm lbf lbf lbf lbf rpm inch mm max. min. min. max.
7⁄16 11,11 5⁄8 15,88 0.375 9,52 B-76 — 906 1 390 1 930 1 080 6 300 — — 0.4375 0.4370 0.6245 0.6255
7⁄16 11,11 5⁄8 15,88 0.438 11,13 B-77 — 1 100 1 700 2 480 1 390 6 300 — — 0.4375 0.4370 0.6245 0.6255
7⁄16 11,11 5⁄8 15,88 0.500 12,70 B-78 M-781 1 290 1 980 3 030 1 690 6 300 0.08 2,0 0.4375 0.4370 0.6245 0.6255
7⁄16 11,11 5⁄8 15,88 0.625 15,88 B-710 — 1 640 2 520 4 130 2 310 6 300 — — 0.4375 0.4370 0.6245 0.6255
7⁄16 11,11 11⁄16 17,46 0.500 12,70 BH-78 — 1 470 2 260 2 780 1 660 8 300 — — 0.4375 0.4370 0.6870 0.6880
0.47 12 0.63 16 0.394 10 — — — — — — — — — 0.4724 0.4720 0.6290 0.6297
0.47 12 0.71 18 0.472 12 — — — — — — — — — 0.4724 0.4720 0.7078 0.7085
1⁄2 12,70 11⁄16 17,46 0.312 7,92 B-85 — 754 1 160 1 580 870 5 500 — — 0.5000 0.4995 0.6870 0.6880
1⁄2 12,70 11⁄16 17,46 0.375 9,52 B-86 M-861 976 1 500 2 200 1 210 5 500 0.08 2,0 0.5000 0.4995 0.6870 0.6880
1⁄2 12,70 11⁄16 17,46 0.438 11,13 B-87 M-871 1 190 1 830 2 840 1 560 5 500 0.08 2,0 0.5000 0.4995 0.6870 0.6880
1⁄2 12,70 11⁄16 17,46 0.500 12,70 B-88 M-881 1 390 2 130 3 460 1 910 5 500 0.08 2,0 0.5000 0.4995 0.6870 0.6880
1⁄2 12,70 11⁄16 17,46 0.625 15,88 B-810 M-8101 1 770 2 720 4 720 2 600 5 500 0.08 2,0 0.5000 0.4995 0.6870 0.6880
1⁄2 12,70 11⁄16 17,46 0.750 19,05 B-812 M-8121 2 120 3 260 5 980 3 290 5 500 0.08 2,0 0.5000 0.4995 0.6870 0.6880
1⁄2 12,70 3⁄4 19,05 0.438 11,13 BH-87 — 1 340 2 060 2 550 1 490 7 500 — — 0.5000 0.4995 0.7495 0.7505
1⁄2 12,70 3⁄4 19,05 0.500 12,70 BH-88 — 1 590 2 450 3 180 1 850 7 500 — — 0.5000 0.4995 0.7495 0.7505
1⁄2 12,70 3⁄4 19,05 0.625 15,88 BH-810 — 2 060 3 180 4 440 2 590 7 500 — — 0.5000 0.4995 0.7495 0.7505
1⁄2 12,70 3⁄4 19,05 0.750 19,05 BH-812 — 2 510 3 850 5 690 3 290 7 500 — — 0.5000 0.4995 0.7495 0.7505
0.51 13 0.75 19 0.472 12 — — — — — — — — — 0.5118 0.5114 0.7469 0.7477
0.55 14 0.79 20 0.472 12 — — — — — — — — — 0.5512 0.5508 0.7863 0.7871
9⁄16 14,29 3⁄4 19,05 0.312 7,92 B-95 M-951 804 1 240 1 780 966 5 000 0.08 2,0 0.5625 0.5620 0.7495 0.7505
9⁄16 14,29 3⁄4 19,05 0.375 9,52 B-96 — 1 040 1 600 2 480 1 350 5 000 — — 0.5625 0.5620 0.7495 0.7505
9⁄16 14,29 3⁄4 19,05 0.438 11,13 B-97 — 1 270 1 950 3 190 1 740 5 000 — — 0.5625 0.5620 0.7495 0.7505
9⁄16 14,29 3⁄4 19,05 0.500 12,70 B-98 — 1 480 2 280 3 900 2 120 5 000 — — 0.5625 0.5620 0.7495 0.7505
9⁄16 14,29 3⁄4 19,05 0.625 15,88 B-910 — 1 880 2 900 5 310 2 890 5 000 — — 0.5625 0.5620 0.7495 0.7505
9⁄16 14,29 3⁄4 19,05 0.750 19,05 B-912 M-9121 2 260 3 480 6 730 3 660 5 000 0.08 2,0 0.5625 0.5620 0.7495 0.7505
9⁄16 14,29 13⁄16 20,64 0.500 12,70 BH-98 — 1 710 2 630 3 580 2 050 6 800 — — 0.5625 0.5620 0.8120 0.8130
9⁄16 14,29 13⁄16 20,64 0.625 15,88 BH-910 — 2 210 3 400 5 000 2 860 6 800 — — 0.5625 0.5620 0.8120 0.8130
9⁄16 14,29 13⁄16 20,64 0.750 19,05 BH-912 — 2 690 4 130 6 410 3 670 6 800 — — 0.5625 0.5620 0.8120 0.8130
0.59 15 0.83 21 0.472 12 — — — — — — — — — 0.5906 0.5902 0.8257 0.8265
0.59 15 0.83 21 0.630 16 — — — — — — — — — 0.5906 0.5902 0.8257 0.8265
5⁄8 15,88 13⁄16 20,64 0.312 7,92 B-105 — 851 1 310 1 980 1 060 4 500 — — 0.6250 0.6245 0.8120 0.8130
5⁄8 15,88 13⁄16 20,64 0.438 11,13 B-107 M-1071 1 340 2 070 3 550 1 910 4 500 0.08 2,0 0.6250 0.6245 0.8120 0.8130
5⁄8 15,88 13⁄16 20,64 0.500 12,70 B-108 M-1081 1 570 2 410 4 330 2 330 4 500 0.08 2,0 0.6250 0.6245 0.8120 0.8130
5⁄8 15,88 13⁄16 20,64 0.625 15,88 B-1010 — 1 990 3 070 5 900 3 180 4 500 — — 0.6250 0.6245 0.8120 0.8130
5⁄8 15,88 13⁄16 20,64 0.750 19,05 B-1012 M-10121 2 400 3 690 7 480 4 020 4 500 0.08 2,0 0.6250 0.6245 0.8120 0.8130
T Symbol denotes Basic Dynamic Load Rating to be used in load-life
calculations taking into consideration the application guidelines and limitations given
in this catalog. Applications involving loads approaching this rating or the tabulated
working load, whichever is the smaller, should be referred to the Torrington
Engineering Sales Office before a final selection is made.
speed
.8
15 20 30 40 50 60 70 80 100 200 300 150 400 500 700 1000 1500 2000 3000 4000 5000 7000 10000 15000 20000 30000
factor
SF
rpm
.9 1.0 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0 6.5 7.0 7.5
X
D
C C
FW FW
Full
Complement
Bearing
Caged
Bearing
S H
shaft surface to be
58 HRC or equivalent
Open End Closed End
Full Complement
Bearings
Check for availability.
Inch-metric conversions given are
for the convenience of the user. The
controlling dimensions are in inches
for nominal inch bearings and in
millimeters for nominal metric
bearings.
Load ratings are based on a minimum raceway hardness of 58 HRC or equivalent.
Load ratings are given in pounds-force: 1 lbf = 0.454kgf = 4.448N
Required Basic Dynamic Load Rating (Cr) = Applied Load • SF • LF • HF (see page E75).
DRAWN CUP NEEDLE ROLLER BEARINGS |
近期推荐轴承型号B-88,
,
6204ZCM,
LM 11949/10,
1211K,
30313DJR ,
6008ZZCM ,
6317ZZXCM,
23148RW33C3,
6317CM,
NUP312BVH,
DAC3577-2CS68,
以上为我司部分轴承型号，如需查找其他型号，可登陆我们的现货中心栏目或致电021-52797858转8008询价,进行详细查询，谢谢！
|
| B-88产品详细图片： |
 |
| KOYO轴承品牌介绍： |
| 光洋KOYO轴承创立于1921年，日本光洋精工株式会社Koyo是一家有着悠久历史和文化、在日本排名第三位的世界综合轴承产品制造商，其生产的各种轴承广泛用于通用机械和其他行业和专业领域，在世界各地用户中享有极高的知名度和优良的品质赞誉。KOYO轴承主导产品有：KOYO滚动轴承、KOYO深沟球轴承、KOYO高精度轴承、KOYO调心轴承、KOYO带座轴承、KOYO平面球轴承、KOYO短圆柱滚子轴承、KOYO直线导轨、KOYO滚珠丝杆、KOYO微小型直线导轨、KOYO交叉滚子导轨、KOYO往轴承复旋转衬套轴承、KOYO滚珠滑组、KOYO凸轮从动轴承等等。 |
上海川代轴承机械有限公司专业销售KOYO轴承 B-88轴承,KOYO轴承品牌供应商,我们为您提供B-88的具体的规格参数及报价，本公司同时销售包括KOYO轴承品牌在内的多种进口轴承，包括深沟球轴承、自动调心球轴承、角接触球轴承、圆柱滚子轴承、滚针轴承、球面滚子轴承、推力轴承、Y-轴承、滚轮轴承，直线轴承，滑动轴承，轴承箱及各种精密机械部件等产品，目前公司拥有现货库存、快捷的物流体系、能在较短的时间内为用户解决轴承的配套供应和提供个性化服务。
欢迎垂询KOYO轴承 B-88轴承价格和库存信息。咨询热线：021-52797858转8008询价 |
